Due to this design, they do not slip and there is no relative motion between the two elements in mesh. Synchronous drives employ the positive engagement of two sets of meshing teeth.
#PULLEYS TIMING BELTS DOWNLOAD#
If you require a taper bore for a Metric or large Classical pulley, then these can often be manufactured to order.More Videos Helpful Videos Download Timing Belt Infographic All other sizes are available in pilot bore including the complete range of Metric timing pulleys. Classical L and H pulleys are available with a taper bore as are 5M, 8M and 14M HTD Profile pulleys. Timing belt pulleys are available for the standard Classical, HTD Profile and Metric belts. With our ability to manufacture special pulleys or offer light weight solutions from aluminium we can offer a solution for a vast array of precision drive systems.
Working in precision applications globally, our range of timing belts and corresponding pulleys have been developed around the industries that we supply daily.
PV pulleys are also available for sections J, K and L Timing Belt Pulleys
#PULLEYS TIMING BELTS ISO#
Groove dimensions conform to ISO 4183 for both eccentricity of outside diameter to bore and groove side wobble tolerance.Īll pulleys are available with a taper bore to suit the Challenge range of stock taper bushes although pilot and QD bush bore pulleys can also be manufactured.Ī wide range of non-standard styles and sizes up to a diameter of 2400mm can be produced. Coupled with our wide range of Shaft Mounted Speed Reducers, they offer a reliable method of reducing motor speeds, which has become an industry standard.Īvailable to suit both wedge and classical belts to ISO 4184. With high quality machined groves and availability from nearly 20 official locations around world, these cost effective and readily available range of pulleys have proven themselves countless times over the last 40 years. Shaft fixing option vary due to the large range of sizes and materials available, but as standard the range of pulleys come with either a taper bore, pilot bore or both types of bores. Metric timing pulleys are also available from lightweight aluminium with a natural finish. The complete range of pulleys available from Challenge are manufactured from high grade close grain GG25 grey cast iron or steel before being phosphated for protection. Manufactured from cast iron or steel, our pulley grooves are machine cut for accuracy and also statically or dynamically balanced (depending upon their size) to grade Q6.3 or better giving peripheral (rim) speeds of up to 40m/s. To complement our wide range of belts, we also manufacture and supply a range of standard and bespoke pulleys for our V belts and Timing belts. Standard and custom - V and Timing Belt Pulleys Please note that a small range of XL pulleys are already available with pilot bores. We supply a very large number of special pulleys to industries all over the word. Please contact us for more details or to discuss your specific requirements.
XL Extra Light and XH Extra Heavy belt pulleys are also available upon request, along with non-stock numbers of teeth, special bores (including bearings) or special pulley arrangements. taper bushes to suit our range of taper bored synchronous timing pulleys are also available from stock for a range of shaft sizes. Our strict quality control procedures ensure the tooth accuracy on all our synchronous timing pulleys, allowing like for like replacement along with timing accuracy. Taper Bore Classical Synchronous Timing Pulleys Our stocked range of classical taper bore timing pulleys cover the Light (L) 3/8” (9.525mm) pitch belts and the Heavy (H) 1/2” (12.7mm) pitch belts.
